P3.91 indoor rental led display RK1000 series
The P3.91 Indoor Rental LED Display RK1000 Series has a high-definition, lightweight, ultra-thin feature, the display video is clear than other products, and the appearance is very delicate because there do no extra lines, it is widely used in concerts and stages.
- Cabinet: 500×1000 mm
- Pixel pitch: P3.91
- Resolution: 65536 dots/sqm
- Seamless connecting tech, high resolution, Presenting the real picture
- The most effective solution for indoor HD Billboard
- Low Consumption, save cost greatly
- High refresh rate, high grey level
Describe
The P3.91 Indoor Rental LED Display RK1000 Series designed to provide a vivid and high quality image for indoor applications, it can take more convenient to your daily life.
This cabinet is very light and thin, and it has a design of humanization handle which can make you move or install it easily on the stage when you have an event.
Feature
For a regular cabinet, you need the screw to fix the power supply and other accessories, but for this updated cabinet, you just pull out the supply, it can make the assemble and dismantling more convenient, then save you lots of time, also there does no extra line that makes the cabinet delicate.
The fast lock can save time when you install and dismantle, it can improve your working affection, and it is compatible same type cabinet such as 500x500mm, you can combine a 500x500mm cabinet connect with a 500x1000mm cabinet to a complete screen with this fast lock, this can save your cost.
When you use the led screen, how to dismantle the module quickly has been a problem, now this cabinet use the function of the magnet, you just need to use the magnetic tool, which can achieve the module dismantled quickly, it can make the installation and repair easier.
Due to the installation environment and structure difference, we need to consider the method of repairing, this cabinet can use modules for front service maintenance, you can choose one method that suits your needs, and it can save much time when you repair the cabinet and modules.
Parameter
- P3.91 outdoor rental LED display 500x1000mm parameter
- RK1000 series for other pixel pitch
| Pixel Pitch | P3.91 |
| LED type | SMD2121 |
| Pixel configuration | 3 in 1 SMD |
| Pixel density | 65,536 pixels/m2 |
| Module dimension(W*H) | 250mmx250mm |
| Module resolution | 64*64dots |
| Drive Method | 1/16 scan |
| Maintenance | Front and back |
| Cabinet size (W*H) | 500*1000mm |
| Cabinet depth | 88mm |
| Cabinet material | Aluminum |
| Cabinet weight | 13.2kg/pcs |
| Brightness | ≥1000 cd/m2 |
| Best Viewing Distance | 4m to 40m |
| Viewing Angle | 140 * 140 |
| Grey Level | 14 Bit |
| Refresh Rate | ≥1920HZ /3840HZ |
| Power consumption(Avg.) | 100w/cabinet |
| Power consumption(Max.) | 300w/cabinet |
| Humidity-operating | 10% ~ 95% |
| Operating Temperature | -20° – 50° C |
| Screen life | ≥100000 hours |
| Controlling System | Synch or Async |
| Certificates | CE, RoHS,FCC, UL |
| Ingress Protection (IP) | IP65 |
| Warranty | 2 Years |
| Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to RGBLEDWORLD. | |
| Pixel Pitch | P2.604 | P2.97 | P3.91 | P4.81 |
| LED type | SMD2121/1515 | SMD2121 | SMD2121 | SMD2121 |
| Pixel configuration | 3-in-1 SMD | 3-in-1 SMD | 3 in 1 SMD | 3-in-1 SMD |
| Pixel density | 147,456 pixels/m2 | 112,896 pixels/m2 | 65,536 pixels/m2 | 43,264 pixels/m2 |
| Module dimension(W*H) | 250*250mm | 250*250mm | 250*250mm | 250*250mm |
| Module resolution | 96*96dots | 84*84dots | 64*64dots | 52*52dots |
| Drive Method | 1/32 scan | 1/21 scan | 1/16 scan | 1/13 scan |
| Maintenance | Front and back | Front and back | Front and back | Front and back |
| Cabinet size (W*H) | 500*1000mm | 500*1000mm | 500*1000mm | 500*1000mm |
| Cabinet depth | 85mm | 85mm | 85mm | 85mm |
| Cabinet material | Aluminum | Aluminum | Aluminum | Aluminum |
| Cabinet weight | 13.2kg/pcs | 13.2kg/pcs | 13.2kg/pcs | 13.2kg/pcs |
| Brightness | ≥1000 cd/m2 | ≥1000 cd/m2 | ≥1000 cd/m2 | ≥1000 cd/m2 |
| Best Viewing Distance | 2.5m to 25m | 3m to 30m | 4m to 40m | 5m to 50m |
| Viewing Angle | 140 * 140 | 140 * 140 | 140 * 140 | 140 * 140 |
| Grey Level | 14 Bit | 14 Bit | 14 Bit | 14 Bit |
| Refresh Rate | ≥1920Hz/3840HZ | ≥1920Hz/3840HZ | ≥1920Hz/3840HZ | ≥1920Hz/3840HZ |
| Power consumption(Avg.) | 120w/cabinet | 110w/cabinet | 100w/cabinet | 100w/cabinet |
| Power consumption(Max.) | 340w/cabinet | 320w/cabinet | 300w/cabinet | 300w/cabinet |
| Humidity-operating | 10% ~ 95% | 10% ~ 95% | 10% ~ 95% | 10% ~ 95% |
| Operating Temperature | -20° – 50° C | -20° – 50° C | -20° – 50° C | -20° – 50° C |
| Screen life | ≥100000 hours | ≥100000 hours | ≥100000 hours | ≥100000 hours |
| Controlling System | Synch or Async | Synch or Async | Synch or Async | Synch or Async |
| Certificates | CE,RoHS,FCC,UL | CE,RoHS,FCC,UL | CE,RoHS,FCC,UL | CE,RoHS,FCC,UL |
| Ingress Protection (IP) | IP31 | IP31 | IP31 | IP31 |
| Warranty | 2 Years | 2 Years | 2 Years | 2 Years |
| Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to RGBLEDWORLD. | ||||
