P3 indoor rental led display LRI3 series

P3 indoor rental LED display 576x576mm is a popular product in the rental market, this is for die-cast aluminum cabinet design, can show you the picture and videos completely, realize seamless infinite splicing of any size, fanless design, save energy,  which makes it can use at many places. Such as exhibitions, video conferences, movie theaters, studios, KTV, nightclubs, and so on.

  • Cabinet: 576×576 mm
  • Pixel pitch: 3mm
  • Die-cast aluminum rental cabinet
  • Fast lock design, a good choice for rental
  • Non-gaps between cabinets
  • 120°(Horizontal) 120°(Vertical) viewing angle
  • 10%~90% RH Working humidity

Feature

Low Consumption

This cabinet with a clean internal layout, a good layout for data cables, power cables, power supply, and the control card, a fanless design, no noise during working, and cooling holes on the back cover of the LED display, it can achieve the lower consumption when it is operating.

Various installation methods

Because the cabinet is light and small, you can use it for fixed or rental, when you use it for rental, you can use hanging bars to make them installed well, when you use it for fixed, you can make a steel structure to install them, it can make the led screen can use in many situations, at the same time, save your cost.

Delicate Cabinet Structure

P3mm indoor rental LED display 576x576mm cabinet with Die-cast aluminum frame design, it is an ultra-light, ultra-thin space-saving, cost-saving, and stylish screen,  one cabinet just 7KG, 80mm thickness, making it portable and easy to transport, saving the labors and time.

Fast lock design

This type of screen with a friendly fast lock design makes LED display cabinets easy to install and assemble, The side locks can tighten up the cabinets when installed, and they can reduce the gaps between cabinets, making the screen seem seamless.

Parameter

Technical indexes Specification
Pixel pitch 3mm
Module size 192mm×192mm
Module resolution 64×64
Module density 111111dots/sqm
Cabinet Size(mm) 576x576x80
Pixel configuration RGB,3 in 1
Red wavelength 625±2nm
Green wavelength 525±2nm
Blue wavelength 470±2nm
Colors 16777216
Best viewing distance 3m—15m
Horizontal viewing angle 140°
Vertical viewing angle 120°
Maximum power consumption 300W/pcs
Average power consumption 100W/pcs
Brightness 1000cd/sqm, adjustable
Grayscale 16bits of per color
Driving method 1/32scanning
Frame frequency 60Hz
Refresh frequency ≥3840 Hz
Working voltage AC220V/110V±10%
IP grade  IP20-45
Working temperature -20°C~80°C
MTBF More than 10,000 hours
Life span More than 100,000hours
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to SZLEDWORLD
Technical indexes Specification Specification
Pixel pitch 3mm 6mm
Module size 192mm×192mm 192mm X 192mm
Module resolution 64×64 32 X 32
Module density 111111dots/sqm 27777dots/m2
Cabinet Size(mm) 576x576x80 576x576x80
Pixel configuration RGB,3 in 1 1R1G1B
Red wavelength 625±2nm 625±2nm
Green wavelength 525±2nm 525±2nm
Blue wavelength 470±2nm 470±2nm
Colors 16777216 16777216
Best viewing distance 3m—15m ≥6m
Horizontal viewing angle 140° 140°
Vertical viewing angle 120° 120°
Maximum power consumption 300W/pcs 300W/pcs
Average power consumption 100W/pcs 100W/pcs
Brightness 1000cd/sqm, adjustable 1000cd/sqm, adjustable
Grayscale 16bits of per color 16bits per color
Driving method 1/32scanning 1/8 or 1/16 scanning
Frame frequency 60Hz 60Hz
Refresh frequency ≥3840 Hz ≥3840 Hz
Working voltage AC220V/110V±10% AC220V/110V±10%
IP grade  IP20-45  IP20-45
Working temperature -20°C~80°C -20°C~80°C
MTBF More than 10,000 hours More than 10,000 hours
Life span More than 100,000hours More than 100,000hours
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to SZLEDWORLD
