P2 LED Screen

P2 LED Screen

P2 LED Screen

P2 LED screen from SZLEDWORLD is engineered having a perfect combination of supreme picture quality, flexible design selections, and environmental operation efficiency. Furthermore, this LED screen is accessible with any form of installation methods, suitable to the particular locations. Due to the superior quality and performance of our P2 LED screen, it becomes progressively vital in all aspects of businesses. It considers as the best option in conveying a compelling messages to customers as well as to creating the highest definition of advertisement or promotional displays.

SZLEDWORLD has unmatched know-how ability to customize and design P2 LED screen based on your general specifications. Whatever sizes, types, pixel pitch, density, and other configurations you want, everything is available at a very cost-effective price. As a top leading P2 LED screen manufacturer, SZLEDWORLD aim to provide impeccable and creative LED screens with quality and satisfaction!

Send us now your design, and we will take care of the rest of the process!

Curved P2 LED Screen
Curved P2 LED Screen
  • Pixel Type: 1R1G1B
  • Module Resolution: 160Px80P
  • Refresh Frequency: 1920Hz – 3840Hz
  • Brightness: 600 – 1,000 nit
  • Viewing Angle: H:140° ; V:140°
  • Available in 320mmx160mm module sizes
P2 Flooring Standing LED Screen
P2 Flooring Standing LED Screen
  • Adjustable color temperature typically ranging from 3200K to 9300K
  • Max. Contrats Rate: 5000:1
  • Input Voltage: AC110V/220V
  • Viewing Degree: (H/V): 140°/120°
  • Module Measurement: 320mm x 160mm
Rental Billboard P2 LED Screen
Rental Billboard P2 LED Screen
  • LED Type: SMD2121
  • Input Voltage: AC100V/240V
  • Pixel Density: 250,000 pixels/sqm
  • Brightness: >1200 cd/sqm
  • IP Rate: IP31
  • Viewing Distance: 4 – 100m
P2 Portable Indoor LED Screen
P2 Portable Indoor LED Screen
  • Service Access: Front / Back
  • IP Grade: IP31
  • Input Voltage: AC110V/240V
  • Brightness: 1200cd/sqm
  • 16 bit of grey scale
  • Life Duration: 100,000 hours
Ultra-Slim P2 LED Screen
Ultra-Slim P2 LED Screen
  • Operating temperature reaching from 20°C – 80°°C
  • LED Configuration: SMD2121
  • 110V/240V AC of input voltage
  • Grey Scale: 14bit
  • Brightness: 500-900 cd/m2
  • IP Category: IP45
P2 3D Interactive LED Screen
  • Input Frequency: AC110/AC220V±10%
  • Hertz Rating: 1920Hz – 3840Hz
  • Brightness: 800 – 1,000 nits
  • Grey scale with 16 bit
  • Operating Humidity: IP31/IP40
  • Lifetime Typical Value: 10% – 90%
6 Products Found.


Experience. SZLEDWORLD has 20 years of professional experience as China’s best LED screen manufacturer.

Sales Network. A variety of products has been distributed for over 100 countries and regions worldwide.

Laboratory.  Our team consists of an expert R&D team with R&D strength. We also built a state-of-the-art industrial laboratory.

Certificates. SZLEDWORLD ensures that every LED screen we produce conform to global market standards and certificates including CE, BIS, RoHS, CCC, ETL, RCM, FCC, AEO, etc.

P2 LED Screen Use Instances

P2 LED Screen: Use Instances

Almost every business uses these contemporary p2 LED screen, including:

  • Malls and stores
  • Guest houses
  • Departments
  • Churches
  • Healthcare facilities
  • Displays of art, etc.

Almost all public notifications and retail advertising can be displayed on the p2 LED screen.

Model P2 LED Screen
Pixel Pitch 2.0 mm
Module Size 320 x 160 mm
Module Resolution 160 x 80 dots
LED Lamp Type SMD 1515 Black LED (3-IN-1 RGB)
Brightness 800–1,200 nits (adjustable)
Refresh Rate 1,920Hz ~ 3,840Hz
Greyscale 16-bit (281 trillion color) / 65,536 shades per primary color
Driving Method 1/40
Min Viewing Distance > 2.0 meter
Pixel Density / m2 250,000 dots
Standard Panel Bare, Steel Iron, Magnesium Alloy
Power Rating (Typ) 150W/m2
Max Power Rating 450W/m2
LED Screen Comparison Between P2 and P3

The P2 and P3 LED screens are very popular right now, especially for structural purposes. The two will be contrasted:

  • P2 has a pixel pitch of 2 mm,
  • Whereas P3 has a pixel pitch of 3 mm.
  • P2’s images are more accurate and clear than P3’s in terms of visual quality.
  • P3 has a farther field of vision than P2, in terms of seeing distance.
Typical Attributes of P2 LED Screen

For businesses in the modern advertising field, P2 LED screens are particularly advantageous.

Remember that every business seeks a promotional approach that is efficient, adaptable, and portable.

P2 LED screen has the following in addition to:

– Easy to use and maintain features.

– Images of a high caliber.

– Displaying content without jerking.

– Easy to modify.

– A black LED arrangement produces a higher contrast ratio.

– Little reflection.

– Wide field of view.

– Enduring and trustworthy.

– Deliver incredible picture quality with a 2.0 mm pixel pitch.

– A variety of information formats, including text, images, videos, and illustrations.

– Send forth crisp, stunning photos.

– Suitable for several installation methods, including hanging and wall.

– The solution may be set up more quickly owing to simple installation.

– LED chips with high efficiency and low power usage.
